For light commercial or larger residential systems.
Gauge: 28 Galvanized
Dimensions: 2 3/4″ metal – 4″ fabric – 2 3/4″ metal
Fabrics Supplied: Durolon, Excelon, Neoprene, Glasseal, Thermafab
Seam: Guard Loc
Item Code: DDEFN4 EFN 2.75x4x2.75 Econo Fab Neopr #10035
| Durolon UL Certified NFPA 701 | ||
|---|---|---|
| DESCRIPTION | SPECIFICATIONS | FEATURES |
| Color: White Base Fabric: Woven Fiberglass Coating: Hypalon |
Weight: 26 oz./sq. yd. Tensile Strength: 225 lbs. x 300 lbs. Tear Strength: 12 lbs. x 12 lbs. Low Temp: -40°F High Temp (Continuous): 250°F |
•Excellent ozone resistance •Excellent resistance to weathering •Best overall acid resistance •Recommended for rooftop applications •Unaffected by mildew |
| EXCELON® UL Classified File# R4462 | ||
|---|---|---|
| DESCRIPTION | SPECIFICATIONS | FEATURES |
| Color: *Black or #Spec Chek Orange Base Fabric: Woven Nylon/Polyester Blend Coating: Vinyl |
Weight: Commercial Grade – 22 oz./sq. yd. Residential Grade – 17 oz./sq. yd. Tensile Strength: 240 lbs. x 220 lbs. Tear Strength: 100 lbs. x 100 lbs. Low Temp: -40°F High Temp (Continuous): 180°F |
·Excellent water resistance ·Excellent tear strength ·Excellent all purpose fabric ·Unaffected by mildew |
| NEOPRENE (Standard Grade) UL Classified File# R4462 | ||
|---|---|---|
| DESCRIPTION | SPECIFICATIONS | FEATURES |
| Color: Black Base Fabric: Woven Fiberglass Coating: Neoprene |
Weight: 22 oz./sq. yd. Tensile Strength: 500 lbs. x 450 lbs. Tear Strength: 12 lbs. x 12 lbs. Low Temp: -40°F High Temp (Continuous): 200°F |
·Extremely resistant to alkalies & gasoline ·Excellent on systems exposed to toxic fumes ·Good general purpose fabric ·Unaffected by mildew |
| Glasseal UL Classified File# R4462 | ||
|---|---|---|
| DESCRIPTION | SPECIFICATIONS | FEATURES |
| Color: Grey & Black Base Fabric: Woven Fiberglass Coating: Vinyl |
Weight: 16 oz./sq. yd. Tensile Strength: 90 lbs. x 90 lbs. Tear Strength: 8 lbs. x 9 lbs. Low Temp: -40°F High Temp (Continuous): 180°F |
·Good, low cost ·Resistant to acids & chemical fumes ·Resistant to grease & alkalies ·Unaffected by mildew |
| Thermafab® UL Classified File# R4462 | ||
|---|---|---|
| DESCRIPTION | SPECIFICATIONS | FEATURES |
| Color: Grey Base Fabric: Woven Fiberglass Coating: Silicon Rubber |
Weight: 17 oz./sq. yd. Tensile Strength: 200 lbs. x 150 lbs. Tear Strength: 50 lbs. x 40 lbs. Low Temp: -65°F High Temp (Continuous): 500°F |
∙Excellent high temp. resistance ·Excellent low temp. resistance ·Excellent chemical resistance ·Extremely low smoke emission ·Excellent ozone resistance ·Excellent resistance to weathering ·Unaffected by mildew |
